EM 01 SPR 200

*Images are representative.

EM 01 SPR 200

Plate Fitting

200 mm Wheel Size
50 mm Wheel Width
180 KG Load Capacity

BRACKET/ FORK / HOUSING

Parts pressed from sheet steel with blue passivated zinc coating, Double stack ball bearing swivel axle, Plastic dust protection, Connection types compatible with swivel head (03-04-05-07), Brake system locking tong and wheel at the same time, Pipe mounted wheel axle, Fixed tong machined from sheet steel matching with table tongs.

WHEEL ( )

Sheet steel with blue passivated zinc plating, Wheel sidewalls made of black rubber tire with polyamide bushing bearings joined with rivets, 82+3 Shore A / -20°C+60°C

TECHNICAL SPECIFICATIONS

Wheel Width:50 mm

All Height:242 mm

Table Dimensions:110x140 mm

Hole Distance:80x105 mm

Total weight: 3214 gr

Load Capacity:180 kg

Wheel Cover:S

Wheel Size:200 mm

Model

To download CAD images of the product you need to make a request. After confirmation of your request, you Single Use Password It will be sent.
