*Images are representative.

EW 01 VBV 200

  • Plate Fitting
  • 200 mm Wheel Size
  • 2x50 mm Wheel Width
  • 2200 KG Load Capacity

BRACKET/ FORK / HOUSING

Welded cast steel tongs and ductile iron table. Butte and tapered bearings. Adjustable crown nut with table connection.

WHEEL ( )

Cast wheel, without hubcaps, double wheel, ball bearing housing

TECHNICAL SPECIFICATIONS
Wheel Width:2x50  mm
All Height:281   mm
Table Dimensions:250x200  mm
Hole Distance:210x160  mm
Total weight: 27251   gr
Load Capacity:2200  kg
Wheel Cover:-
Wheel Size:200  mm
THIS SERIES SAME PRODUCTS

EM 01 ZMP 200

Plate Fitting

  • Wheel Size200 mm
  • Wheel Width50 mm
  • Load Capacity230 kg

EM 01 ZKZ 200

Plate Fitting

  • Wheel Size200 mm
  • Wheel Width50 mm
  • Load Capacity230 kg

EM 01 ZMP 200

Plate Fitting

  • Wheel Size200 mm
  • Wheel Width50 mm
  • Load Capacity230 kg

EW 01 HBZ 200 F

Plate Fitting, With Brake

  • Wheel Size200 mm
  • Wheel Width2x50 mm
  • Load Capacity1500 kg
