EM 01 SMR 200 F

  • Plate Fitting
  • |
  • Brake
  • 200 mm Wheel Size
  • 50 mm Wheel Width
  • 180 KG Load Capacity

BRACKET/ FORK / HOUSING

Bracket made of pressed steel, white zinc plated, double ball bearing swivel head, plastic dustguard, wheel axle with bolt and nut

WHEEL ( )

Wheel centre made of pressed steel, black rubber tyre(85 Shore A), Without threadguards,roller bearing

TECHNICAL SPECIFICATIONS
Wheel Width:50  mm
All Height:242   mm
Table Dimensions:115x141  mm
Hole Distance:80x105  mm
Total weight: 3498   gr
Load Capacity:180  kg
Wheel Cover:S
Wheel Size:200  mm
